When people think Durable, Premium water tanks, they think Pioneer
Pioneer has been building steel water tanks since 1988, starting in the harsh conditions of Western Australia and growing into the benchmark for large-capacity storage in more than 35 countries. Three decades of refinement show up in every detail — premium BlueScope steel, a patented wall profile, and the industry's only antimicrobial liner, all designed around a 30-year service life.
20-Yr
Tank & Liner Warranty
5K–100K+
Gallon Capacities
30+
Years of Engineering
NSF 61
Drinking-Water Certified
Pioneer Water Tanks
Tank Sizes
Models of Pioneer Water Tanks include:
XLR Domestic Series
- Designed for rural and domestic applications
- Designed for installation on a sand pad or concrete ring beam foundation
XLE Commercial Series
- Designed for permitted commercial and seismic applications, including fire
- Designed for installation on a concrete ring beam foundation
Special Order Sizes Available
Special order tank sizes beyond 100,000 gallons, with a wide variety of accessories and COLORBOND® steel colors available for residential, agricultural, commercial, and fire protection applications.
| Pioneer Model |
Tank Diameter |
Tank Height |
Capacity (Gallons) |
Net Usable (Gallons*) |
|---|---|---|---|---|
| XL 04/02 | 11' 0" | 7' 2" | 4,900 | 4,340 |
| XL 08/02 | 15' 5" | 7' 2" | 9,907 | 8,510 |
| XL 10/02 | 17' 7" | 7' 2" | 12,946 | 11,200 |
| XL 13/02 | 19' 9" | 7' 2" | 16,392 | 14,150 |
| XL 15/02 | 22' 0" | 7' 2" | 20,243 | 17,500 |
| XL 23/02 | 26' 4" | 7' 2" | 29,093 | 25,200 |
| XL 30/02 | 30' 9" | 7' 2" | 39,626 | 34,300 |
| XL 40/02 | 35' 2" | 7' 2" | 51,785 | 44,850 |
| XL 50/02 | 39' 6" | 7' 2" | 65,567 | 56,750 |
| XL 50/03 | 39' 6" | 10' 7" | 97,148 | 88,000 |
*Net usable capacity for fire protection.
